Repair of the bridge over the Berkel

The bridge has a 3-span superstructure in reinforced concrete construction with spans of
8.25 m/ 15.50 m/ 8.25 m. The clear width between the railings is 2.00 m.

Essential services:

• Supply and install approx. 70 m of dismantled steel railings and curved railings
• Approx. 65 m² removal of the bituminous surfacing on the superstructure
• approx. 80 m demolition of concrete upstand at the cornice area
• Repair approx. 80 m² concrete superstructure panel, prepare concrete base
• Prepare approx. 100 m² surface of the superstructure soffit, produce surface treatment in accordance with OS-C
• Install approx. 5 tonnes of PC mortar incl. bonding bridge on superstructure panel as levelling mortar
• Apply approx. 80 m² surface treatment of flexibilised reactive resin
